DBXK5 | Embroidery | Titanium | #70/10
larger eye to allow embroidery threads (like rayon or polyester) to pass through more easily with less friction and breakage.
Technical Specifications
Schmetz, the DBxK5 is engineered for high functional reliability and resistance to deflection.
- Shank Type: Round shank (not for home machines).
- Shank Diameter: 1.62mm.
- Length to Eye: 33.9mm.
- Overall Length: 37.5mm.
- Special Feature: Larger eye compared to standard needles of the same size.
- Equivalent Systems: 1738 KK, DB-N20, CANU 13:80.
- PD(Titanium): Features a titanium nitride coating that is twice as hard as chrome, increasing needle life by up to 3 times and reducing heat buildup.
Common Point Styles
- RG (Normal Round Point / Small Ball Point): The standard for most embroidery. It is suitable for both knitted and woven fabrics as it displaces loops to prevent material damage.
- FFG/SES (Light Ball Point): Ideal for knitted fabrics to prevent snags.
- Sharp Point: Used for tightly woven fabrics and caps to ensure precise penetration.
Machine Compatibility
The DBxK5 is the standard needle for a wide range of industrial single and multi-head embroidery machines:
- Major Brands: Titan, Tajima, Barudan, Brother (industrial), SWF, Happy, Toyota, and Melco.
- Other Compatible Brands: ZSK, Meistergram, Pfaff (industrial), and many Chinese-made commercial machines
